Hytera MNC580

The Hytera MNC580 is a 3G/4G Android Mobile Radio, with a touch display that can be permanently fixed in a vehicle or office.

Category:

General Specifications

Dimensions (H x W x D) 170 x 80 x 85 mm
Weight 380g
Screen Size 3.5-inch Touch LCD
OS Android 7.0
RAM Capacity 1GB
ROM Capacity 8GB
Micro SD Card Slot 1
SIM Card Slot 1
Operating Voltage 10-24V DC
Microphone 1
Speaker 4W (6W Max.)
Operating Temperature -30°C to +75°C
Pre-installed APP Hytera HyTalk

Standards and Frequencies

TDD-LTE: Band38/40/41
FDD
-LTE:Band1/3/5/7/8/20/28
WCDMA: Band 1/2/5/8
GSM/GPRS/EDGE: Band2/3/5/8
Frequency Bands
WIFI 2.4GHz,IEEE 802.11 b/g/n
Positioning GPS (AGPS)/GLONASS/BDS
BT V4.0/V3.0/V2.1

Interface

Antenna Port SMA
GPS Antenna Port SMA
Micro USB 2.0 OTG Support
External Audio Port Support
Microphone Jack Support
